MB Quart MDR2.0S2W Bluetooth Source Unit / Nautic Speakers

MB Quart MDR2.0S2W Bluetooth Source Unit / Nautic Speakers



MB Quart 160 watt two speaker audio system with 6.5″ coaxial speakers and Bluetooth source unit.



Features:

Compatible Vehicle Fitment	Universal
Marine Grade Protection / IPX Rating	Source Unit: IPX5, Speakers: IPX67
Source Unit Features	LCD Display, Apple Control. Input types: BT, RCA, USB. Four channels of output: these channels remain active when running external amplifiers (RCA Output) to run additional speakers in the vehicle.
Speaker Features	Tweeter: 0.75" composite dome, Frequency Response: 35Hz to 21kHz, Sensitivity: 89db, 80W Maxx / 40W RMS
Time and Tools	Basic hand tools.



Specifications:

Weight	6.2 lbs
Dimensions	10.5 × 9 × 8 in
Type	Vehicle Kit
Brand	MB Quart
Series	Tuned Audio System
Category	Marine, RV
Condition	New
Color	White
IPX Rating	Source Unit: IPX5, Speakers: IPX67
Compatible Vehicles	Universal
Vehicle Kit Total System Power (watts)	160
Additional Details	See Kit Features & Benefits for product components and details



Kit Includes:

Source Unit	MDR2.0W - Power Requirements: DC 12v, Negative Ground; Maximum Output Power: 4 x 40 watts; Current Draw: 10 AMPS (max); Stereo Separation: -64.1dB @ 5kHz; Bluetooth Range: 32 Feet
Source Unit Mounting	Mounting Hole: 7" x 2"; Mounting Depth: 4"
Front Speakers	Two 6.5 inch coaxial speakers with 0.75 inch composite dome tweeters: Water resistant composite polypropylene cone with temperature stable UV Butyl rubber surround mounted on a lightweight composite frame.
Front Speakers Mounting	Composite Integrated Grill: UV treated against sun fade and waterproof and are integrated into speaker frame for simple installation. Stainless Steel Screws.



Instructions:

• MBQuart-Nautic-Speakers-NF1-QSG-Rev1.pdf

• MBQuart-SrcUnit-MDR2-0-Install-Rev1_0.pdf
