ARB Single Motor Portable 12V Air Compressor

ARB Single Motor Portable 12V Air Compressor



This compact, portable, 12V air compressor is designed to take with you on the go. Conveniently air up after a day on the trails or a weekend at the beach. The impact resistant weather-proof case, provides protection for the compressor in various conditions, making it more versatile and reliable for outdoor use. The stainless-steel heat shield covers the hot touch areas of the compressor making it safer for operation.

Air On-the-Go: When it comes to air, well, we can't live without it. ARB portable air compressors are an incredible resource for work and play; just ask the thousands of off-roaders around the world whom praise their reliability and performance. This hard-earned reputation stems from superior engineering and quality materials that stand the test of time.

Compare Options:

• Maximum Output (Twin Motor): Providing optimum power, the ARB twin motor design delivers class-leading air flow for fast inflation purposes. The twin motors incorporate internal thermal protection against extreme temperature damage while a heavy duty in-line MAXI fuse provides professional circuit protection.
• High Output (Single Motor): With a class-leading flow rate, the single motor compressor has been designed for fast tire inflation and a range of other functions whether they be for work or play.



Features & Benefits:

• Built-in pressure switch with over pressure safety valve
• Motor is internally thermal protected against extreme temperature damage
• Weather proof impact resistant polypropylene carry case
• Duty cycle is 50%
• Hard anodized cylinder bore for reduced friction
• Teflon impregnated carbon fiber piston seals
• Handy neoprene pocket to store air hose and accessories



Installation Instructions:

• ARB 4x4 Accessories - ARB USA Warranty Booklet



Specifications:

Volts			12V
Width			12.1 in
Height			7.2 in
Length			14.0 in
Weight			15.4 lb
Max Psi			100
Max Amps			32
IP Rating			IP55
Duty Cycle			50% 30/30
Air Flow OPSI			3.08CFM
Air Flow 29PSI			2.34CFM
Design			Portable
Specifications	Air Locker Activation System (12V)	High Output 12V	High Output 24V	Maximum Performance 12V	Maximum Performance 24V
Current Draw (No Load)	5.5A	14A	7A	28A	14A
Air Flow 0 KPA	27.7L/m	87.2L/m	87.2L/m	174.4L/m	174.4L/m
Air Flow 0 Psi	0.98CFM	3.08CFM	3.08CFM	6.16CFM	6.16CFM
Current Draw (Load)	7.5A	25A	12.6A	50A	25A
Air Flow 200 KPA	19.7L/m	66L/m	66L/m	132L/m	132L/m
Air Flow 29 Psi	0.70CFM	2.34CFM	2.34CFM	4.68CFM	4.68CFM
Duty Cycle	35%	50%	50%	100%	100%
Load Protection	No	Yes (In loom)	Yes (In loom)	Yes (In loom)	Yes (In loom)
Air Locker Solenoid Manifold	Yes	Yes	Yes	No	No
Thermally Protected Motor	No	Yes	Yes	Yes	Yes
